MPN
PWS-1K11P-1R
Total Available Quantity
-
Specifications
Form Factor
1U
Max Output Power
1010W
Modularity
N/A
Min Operating Temperature
0°C
Max Operating Temperature
50°C
Power Connector
19-Pair Gold Finger
AC Input Range
-36Vto-76V
DC Output Voltage 1
+12V1
DC Output Voltage 2
+12V2
DC Output Voltage 3
+5Vsb
Energy Efficiency
0.9
Hazardous Materials
CB / CCC / CE
Height
40mm
HTS
8504.40.9530
Length
346mm
Max Input Current
30A
Maximum Load 1
70A
Maximum Load 2
83A
Maximum Load 3
4A
MTBF (hours)
150K
Package Quantity
1
Packaging
Bulk
PFC Function
No
Power Cable (Region)
NA
Power Protection
OCP / OTP / OVP / SCP / UVP
Storage Temperature
-10°C to 60°C
Width
76mm
