MPN
1053354-1
Manufacturer
Description
Connector, Jack; SMA; Printed Circuit Board; Straight; Stainless Steel; 50 Ohms
MPN
1053354-1
Total Available Quantity
-
Specifications
Connector Type
SMA
Gender
Female
Max Frequency
12.4GHz
Impedance
50O
Orientation
Vertical
Contact Plating
Gold
Contact Material
Copper
Mount
PCB, Through Hole
Packaging
Bulk
RoHS
Compliant
Body Material
Stainless Steel
Body Plating
Gold
Case/Package
SMA
Depth
6.3mm
Dielectric Material
PTFE
ELV
Compliant
Fastening Type
Threaded
Frequency
18GHz
Height
9.5mm
Insulation Material
Polytetrafluoroethylene
Lead Free
Lead Free
Length
6.3mm
Lifecycle Status
Production
Manufacturer Lifecycle Status
Production
Max Operating Temperature
165°C
Min Operating Temperature
-65°C
Number of Contacts
1
Number of Positions
1
Outside Diameter
6.35mm
PCB Mounting Orientation
Vertical
Plating
Gold
Polarity
Normal
Radiation Hardening
No
REACH SVHC
No
Sealable
No
Tail Length
3.9mm
Termination
Solder
