MPN
MCP1825S-3002E/DB
Manufacturer
Description
IC; Linear Regulator; Max. Input; 6V; Output; 3V; 500MA; Accuracy; 0.5%; SOT223-3
MPN
MCP1825S-3002E/DB
Total Available Quantity
-
Main Attributes
Case/Package
SOT-223
Package Quantity
78
Packaging
Tube
Specifications
Accuracy
0.5%
Contact Plating
Tin
Dropout Voltage
210mV
Height
1.6mm
Input Bias Current
120µA
Lead Free
Lead Free
Length
6.5mm
Lifecycle Status
Production
Max Input Voltage
6V
Max Operating Temperature
125°C
Max Output Current
500mA
Min Input Voltage
2.1V
Min Operating Temperature
-40°C
Min Output Voltage
3V
Mount
Surface Mount
Nominal Output Voltage
3V
Number of Channels
1
Number of Outputs
1
Number of Pins
3
Output Current
500mA
Output Type
Fixed
Output Voltage
3V
Output Voltage Accuracy
0.5%
Polarity
Positive
Quiescent Current
220µA
Radiation Hardening
No
REACH SVHC
No
RoHS
Compliant
Schedule B
8542390000
Width
3.5mm
