MPN
05-50011-00
Total Available Quantity
500
Lead time to Ship
2-3 weeks
Ships from
USA
Country of Origin
-
Date Code
23+
Main Attributes
Series
MegaRAID
Class
Server
Model Number
9460-16i
Specifications
Processor
SAS3516
Data Transfer Rate
12Gb/s (SAS), 64Gb/s (NVMe)
JBOD Mode
Yes
Max Devices Supported (NVMe)
24
Max Devices Supported (SAS/SATA)
240
RAID Levels
0, 1, 10, 5, 50, 6, 60
Storage Interface Connectors
SFF-8643 (x4)
Supported Devices
SAS/SATA/PCIe (NVMe)
Cache Memory
4GB
Compatible Cache Backup Options
CVPM05
Form Factor
Low-Profile
HTS
8471.80.1000
Internal Ports
16
Max Operating Temperature
55°C
Min Operating Temperature
0°C
MTBF
> 3,000,000 hours at 40°C
Operating Humidity
20% to 80% Non-condensing
Package Quantity
1
Packaging
Bulk
Physical Dimensions
6.127in x 2.712in
System Interface
PCIe 3.0 x8
Typical Power
17W
