MPN
RPS8-500ATX-GB
Total Available Quantity
-
Main Attributes
Series
PS8
Specifications
Form Factor
Mini ATX
Input Frequency
47Hz - 63Hz
Max Input Current
6A
Max Output Power
500W
Modularity
N/A
Min Operating Temperature
0°C
Max Operating Temperature
50°C
Power Connector
ATX 24-pin
80 PLUS Certification
80 Plus Gold
AC Input Range
100V-240V
Brand
FSP
DC Output Voltage 1
+3.3V
DC Output Voltage 2
+5V
DC Output Voltage 3
+12V
DC Output Voltage 4
-12V
DC Output Voltage 5
-5V
DC Output Voltage 6
+5Vsb
Hazardous Materials
CB / CCC / CE / FCC / KC / TUV / UL
Height
84mm
HTS
8504.40.9530
Length
190mm
Maximum Load 1
20A
Maximum Load 2
20A
Maximum Load 3
40A
Maximum Load 4
0.5A
Maximum Load 5
0.3A
Maximum Load 6
3A
MTBF (hours)
100K
Package Quantity
1
Packaging
Bulk
Power Cable (Region)
NA
Power Protection
OCP / OTP / OVP / SCP
Storage Temperature
-20°C to 80°C
Width
150mm
MPN
RPS8-500ATX-GB
