MPN
SML-310VTT86
Manufacturer
Description
LED Uni-Color Red 2-Pin Chip 0603(1608Metric) T/R / LED RED CLEAR 0603 SMD
MPN
SML-310VTT86
Total Available Quantity
-
Main Attributes
Luminous Intensity
4mcd
Forward Voltage
2V
Forward Current
20mA
Dominant Wavelength
630nm
Lens Style
Clear
Viewing Angle
140°
Color
Red
Specifications
Mount
Surface Mount
Case/Package
0603
Number of Pins
2
Packaging
Tape & Reel
Illumination Color
Red
Reverse Voltage
4V
Test Current
20mA
Lens Transparency
Clear
Min Operating Temperature
-30°C
Max Operating Temperature
85°C
RoHS
Compliant
Case Code (Imperial)
0603
Case Code (Metric)
1608
Current
2A
Height
900µm
Lead Free
Lead Free
Length
1.6mm
Lens Color
Clear, Colorless
Number of LEDs
1
Power Dissipation
55mW
Radiation Hardening
No
Voltage
4V
Wavelength
650nm
Width
800µm
MPN
SML-310VTT86
Total Available Quantity
-
